Why to use?
1. Electromagnetic Design and Optimization
Motors and Generators: Optimize energy conversion with high efficiency and minimal losses.
Sensors and Actuators: Ensure accurate performance across various environmental conditions.
Transformers and Solenoids: Analyze key performance parameters such as flux and inductance.
2. Advanced Material Analysis
Account for demagnetization in permanent magnets, frequency-dependent losses, and anisotropic effects.
Verify service life and ensure materials perform under various operating conditions.
3. System-Level Integration
Simulate interactions across components using 1D, 2D, or full 3D modeling approaches.
Export sub-component models for co-simulation with Simcenter Amesim, Simcenter Flomaster, and other tools.
Key Benefits
1. Accurate Physics Modeling – Solve Complex Electromagnetic Challenges
Model manufacturing processes, temperature-dependent material properties, magnetization, and demagnetization. Incorporate vector hysteresis and advanced material nonlinearities for precise analysis.
2. Optimize System Efficiency – Save Time with Automated Processes
Utilize fully parameterized CAD functionality for seamless workflows. Leverage scripting capabilities to automate repetitive tasks, enhancing simulation efficiency.
3. Simulate Motion and Interaction – Six Degrees of Freedom
Built-in motion solver with smart re-meshing technology supports magnetic levitation and complex motion scenarios. Accurately account for mechanical interactions such as inertia, mass, and spring forces.
4. Coupled Thermal-Electromagnetic Analysis – Enhance Reliability
Integrate electromagnetic and thermal solvers to analyze steady-state and transient temperature distributions. Predict thermal performance, including losses from eddy currents and hysteresis.
TechSim Positioning – Empowering Electromagnetic Innovation
Deep Expertise in Electromagnetic Simulation
TechSim provides unparalleled support to maximize the potential of Simcenter MAGNET, enabling engineers to tackle complex electromagnetic challenges.
Integrated System-Level Solutions
Ensure seamless integration of Simcenter MAGNET with other Simcenter tools for complete system modeling and optimization.
Comprehensive Training and Support
TechSim offers training, customization, and support to accelerate adoption and deliver the best simulation results.
Technical Capabilities
1. Low-Frequency Electromagnetic Simulation
Perform static, harmonic, and transient analyses for motors, transformers, and other devices.
Optimize designs considering material properties, hysteresis loss, and nonlinearities.
2. Electromagnetic Motion Simulation
Simulate rotational, linear, and arbitrary motion with six degrees of freedom.
Include mechanical effects like viscous friction and constraints for realistic motion analysis.
3. Transient and AC Electromagnetic Simulation
Model time-varying currents, switching effects, and eddy currents.
Simulate skin and proximity effects for high-frequency applications.
4. Thermal-Electromagnetic Co-Simulation
Couple electromagnetic and thermal solvers for steady-state and transient temperature analysis.
Evaluate thermal losses in windings and cores for improved reliability.
5. Advanced Material Modeling
Simulate temperature dependencies, hysteresis, and demagnetization for comprehensive material insights.
Include anisotropic and nonlinear material properties for highly accurate simulations.
